| Place of Origin: | China |
| Brand Name: | L80-13%Cr |
| Certification: | API-5CT |
| Model Number: | 2-3/8"--4-1/2" |
| Minimum Order Quantity: | 20ton |
|---|---|
| Price: | USD |
| Payment Terms: | T/T, L/C |
| Name: | OCTG Tubing | Material Grade: | L80-13%Cr |
|---|---|---|---|
| Standard: | API 5CT | Size: | 2-3/8"--4-1/2" |
| Certification: | ISO API CE | Grade: | API K55 |
| Length: | 1-12m | Usage: | Oil Recovery |
| High Light: | black painting OCTG Tubing,50mm OCTG Tubing,OCTG Tubing for mechanical structure |
||
used for the transportation of crude oil
and natural gas from an oil or gas layer to the surface
after drilling is complete. It is made to withstand the
pressure generated from the extraction process.
| O.D. | Nominal mass | O.D. | w.t. | Nominal weight | Type of pipe end | |||||||||
| (lb/ft) | (kg/m) | |||||||||||||
| Threaded and coupled | Threaded and coupled | Grade | ||||||||||||
| In. | NUE | EUE | In. | mm | In. | mm | NUE | EUE | J-55 | L-80 | N-80 | C-90 | T-95 | P-110 |
| 2 3/8" | 4.00 | -- | 2.375 | 60.32 | 0.169 | 4.24 | 5.95 | -- | PN | PN | PN | PN | PN | PNU |
| 4.60 | 4.70 | 2.375 | 60.32 | 0.190 | 4.83 | 6.85 | 6.99 | PNU | PNU | PNU | PNU | PNU | PNU | |
| 5.80 | 5.95 | 2.375 | 60.32 | 0.254 | 6.45 | 8.63 | 8.85 | -- | PNU | PNU | PNU | PNU | -- | |
| 6.60 | -- | 2.375 | 60.32 | 0.295 | 7.49 | 9.82 | -- | -- | P | -- | P | P | -- | |
| 7.35 | 7.45 | 2.375 | 60.32 | 0.336 | 8.53 | 10.94 | 11.09 | -- | PU | -- | PU | PU | PNU | |
| 2 7/8" | 6.40 | 6.50 | 2.375 | 73.02 | 0.217 | 5.51 | 9.52 | 9.67 | PUN | PNU | PNU | PNU | PNU | PNU |
| 7.80 | 7.90 | 2.375 | 73.02 | 0.276 | 7.01 | 11.61 | 11.76 | -- | PNU | PNU | PNU | PNU | PNU | |
| 8.60 | 8.70 | 2.375 | 73.02 | 0.308 | 7.82 | 12.80 | 12.95 | -- | PNU | PNU | PNU | PNU | -- | |
| 9.35 | 9.45 | 2.375 | 73.02 | 0.340 | 8.64 | 13.91 | 14.06 | -- | PU | -- | PU | PU | -- | |
| 10.50 | -- | 2.375 | 73.02 | 0.392 | 9.96 | 15.63 | -- | -- | P | -- | P | P | -- | |
| 11.50 | -- | 2.375 | 73.02 | 0.440 | 11.18 | 17.11 | -- | -- | P | -- | P | P | -- | |
| 3 1/2" | 7.70 | -- | 3.500 | 88.90 | 0.216 | 5.49 | 11.46 | -- | PN | PN | PN | PN | PN | PNU |
| 9.20 | 9.30 | 3.500 | 88.90 | 0.254 | 6.45 | 13.69 | 13.84 | PNU | PNU | PNU | PNU | PNU | -- | |
| 10.20 | -- | 3.500 | 88.90 | 0.289 | 7.34 | 15.18 | -- | PN | PN | PN | PN | PN | PNU | |
| 12.70 | 12.95 | 3.500 | 88.90 | 0.375 | 9.52 | 18.90 | 19.27 | -- | PNU | PNU | PNU | PNU | -- | |
| 14.30 | -- | 3.500 | 88.90 | 0.430 | 10.92 | 21.28 | -- | -- | P | -- | P | P | -- | |
| 15.50 | -- | 3.500 | 88.90 | 0.476 | 12.09 | 23.07 | -- | -- | P | -- | P | P | -- | |
| 17.00 | -- | 3.500 | 88.90 | 0.530 | 13.46 | 25.30 | -- | -- | P | -- | P | P | -- | |
| 4" | 9.50 | -- | 4.000 | 101.60 | 0.226 | 5.74 | 14.14 | -- | PN | PN | PN | PN | PN | -- |
| 10.70 | 11.00 | 4.000 | 101.60 | 0.262 | 6.65 | -- | 16.37 | PU | PU | PU | PU | PU | -- | |
| 13.20 | -- | 4.000 | 101.60 | 0.330 | 8.38 | 19.64 | -- | -- | P | -- | P | P | -- | |
| 16.10 | -- | 4.000 | 101.60 | 0.415 | 10.54 | 23.96 | -- | -- | P | -- | P | P | -- | |
| 18.90 | -- | 4.000 | 101.60 | 0.500 | 12.70 | 28.13 | -- | -- | P | -- | P | P | -- | |
| 22.20 | -- | 4.000 | 101.60 | 0.610 | 15.49 | 33.04 | -- | -- | P | -- | P | P | -- | |
| 4 1/2" | 12.60 | 12.75 | 4.500 | 114.30 | 0.271 | 6.88 | 18.75 | 18.97 | PUN | PNU | PNU | PNU | PNU | -- |
| 15.20 | -- | 4.500 | 114.30 | 0.337 | 8.56 | 22.62 | -- | -- | P | -- | P | P | -- | |
| 17.00 | -- | 4.500 | 114.30 | 0.380 | 9.65 | 25.30 | -- | -- | P | -- | P | P | -- | |
| 18.90 | -- | 4.500 | 114.30 | 0.430 | 10.92 | 28.13 | -- | -- | P | -- | P | P | -- | |
| 21.50 | -- | 4.500 | 114.30 | 0.500 | 12.70 | 32.00 | -- | -- | P | -- | P | P | -- | |
| 23.70 | -- | 4.500 | 114.30 | 0.560 | 14.22 | 35.27 | -- | -- | P | -- | P | P | -- | |
| 26.10 | -- | 4.500 | 114.30 | 0.630 | 16.00 | 38.84 | -- | -- | P | -- | P | P | -- | |
| P-Plain; N-No threading and no coupling; U-Upset with threading and coupling | ||||||||||||||
