Place of Origin: | China |
Brand Name: | J55/K55/N80/L80/P110 |
Certification: | API-5CT, ISO9001 |
Model Number: | 2-3/8" |
Minimum Order Quantity: | 20ton |
---|---|
Price: | USD |
Payment Terms: | T/T, L/C |
Name: | OCTG Tubing | Material Grade: | J55 K55 N80 L80 P110 |
---|---|---|---|
Standard: | API 5CT | Certification: | API-5CT, ISO9001 |
Surface Treatment: | Varnish, Black Painting, Varnish,FBE, 3PE,etc. | Thickness: | 6 - 16 Mm |
High Light: | Natural Gas OCTG Tubing,Transportation API 5CT TUBING,Crude Oil OCTG Tubing |
Elongation Crude Oil Pipe Ultimate Yield Strength API 5CT For Gas Transmission
Tubing and its coupling is one of main products to be coivered with the quality system. The product is stable and reliable in quality, characteristic data are in accordance with the requirement of API Spec 5CT Specification for Casing and Tubing and API Std. 5B Specification for Machining, Measurement and Inspection of Casing, Tubing and Line Pipe. It is reliable in performance, long in life and can meet the requirments of oil production operation.
O.D. | Nominal mass | O.D. | w.t. | Nominal weight | Type of pipe end | |||||||||
(lb/ft) | (kg/m) | |||||||||||||
Threaded and coupled | Threaded and coupled | Grade | ||||||||||||
NUE | EUE | In. | mm | In. | mm | NUE | EUE | J-55 | L-80 | N-80 | C-90 | T-95 | P-110 | |
2 3/8" | 4.00 | -- | 2.375 | 60.32 | 0.169 | 4.24 | 5.95 | -- | PN | PN | PN | PN | PN | PNU |
4.60 | 4.70 | 2.375 | 60.32 | 0.190 | 4.83 | 6.85 | 6.99 | PNU | PNU | PNU | PNU | PNU | PNU | |
5.80 | 5.95 | 2.375 | 60.32 | 0.254 | 6.45 | 8.63 | 8.85 | -- | PNU | PNU | PNU | PNU | -- | |
6.60 | -- | 2.375 | 60.32 | 0.295 | 7.49 | 9.82 | -- | -- | P | -- | P | P | -- | |
7.35 | 7.45 | 2.375 | 60.32 | 0.336 | 8.53 | 10.94 | 11.09 | -- | PU | -- | PU | PU | PNU | |
P-Plain; N-No threading and no coupling; U-Upset with threading and coupling |
